High-Temperature Crystal Oven HP200
Features: • Temperature range: 25 - 220 °C • Suitable for larger crystals: • Aperture (max): 12 x 12 mm • Length (max): 30 mm • High long-term stability • High temperature homogeneity Heatpoint series… Read more →
Volume discount
- 5–9 units −5%
- 10+ units −10%
Applied in your cart. Quantities of any variant of this product count together.
Configure & order — pick a catalog variant or configure your own
Product
| SKU | Product Type | Crystal Size, mm | Mount Outer Diameter | Mount Thickness | Maximum Operating Temperature | |
|---|---|---|---|---|---|---|
| HP200-12x12 | HT Oven HP200 | 12x12x30 | 50.8 mm | 69 mm | 220 °C |
2 in stock
Ships in: 2–5 calendar days
$1,140
|
| HP200-3x3 | HT Oven HP200 | 3x3x30 | 50.8 mm | 69 mm | 220 °C |
3 in stock
Ships in: 2–5 calendar days
$1,140
|
| HP200-4x4 | HT Oven HP200 | 4x4x30 | 50.8 mm | 69 mm | 220 °C |
Out of stock
Ships in: 47–50 calendar days
$1,140
|
| HP200-6x6 | HT Oven HP200 | 6x6x30 | 50.8 mm | 69 mm | 220 °C |
2 in stock
Ships in: 2–5 calendar days
$1,140
|
| HP200-8x8 | HT Oven HP200 | 8x8x30 | 50.8 mm | 69 mm | 220 °C |
Out of stock
Ships in: 47–50 calendar days
$1,140
|
| HP200L-3x3 | HT Oven HP200L | 3x3x50 | — | — | 220 °C |
Out of stock
Ships in: 47–50 calendar days
$1,188
|
We can make this for you
No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.
Specifications
| Sealing | Not Sealed |
| Maximum Operating Temperature | 220 °C |
Description
Features:
- Temperature range: 25 - 220 °C
- Suitable for larger crystals:
- Aperture (max): 12 x 12 mm
- Length (max): 30 mm
- High long-term stability
- High temperature homogeneity
Heatpoint series HP200 oven is the perfect solution for ensuring high-temperature stabilization for temperature-sensitive optical elements such as LBO, DKDP, and CLBO nonlinear crystals. HPC200 allows temperature fine-tuning in 0.1 °C steps for operation from room temperature (~25 °C) up to 220 °C.
Temperature control is an easy task with a set consisting of an HP200 oven and an HPC controller. HPC controller has an OLED display and a knob for easy control of the most frequently tunable parameters, such as temperature and temperature ramp rate. Using HP200 and HPC as a high-temperature kit ensures long-term stability of ±0.03 °C, making HP200 one of the market's most precise and stable ovens.
If you are looking for even more advanced control and monitoring, a kit of HP200 oven with HPC thermocontroller also features USB-C and CAN connections, allowing for easy integration with your existing lab equipment.
We also offer HP200 ovens in sealed design (with anti-reflection coated optical windows) under request. Sealed ovens ensure higher temperature stability, when used with larger aperture nonlinear crystals.
