Polarization Plane Rotators
• Made of crystalline quartz • Intended to rotate beam polarization plane strictly to an appropriate angle using the circular birefringent effect As compared to a waveplate, a rotator has an intrinsic advantage of… Read more →
Volume discount
- 5–9 units −5%
- 10+ units −10%
Applied in your cart. Quantities of any variant of this product count together.
Configure & order — pick a catalog variant or configure your own
Product
Design Wavelength Range
244 nm - 1064 nm · 14 values
Any
nm
nm
Rotation Angle
45 Deg - 90 Deg · 2 values
Any
Deg
Deg
Surface 1, Wavelength 1
Wavelength
244 nm - 1064 nm · 14 values
Any
nm
nm
Reflectivity, %
0 % - 0.5 % · 2 values
Any
%
%
28
catalog variants — refine the spec to narrow it down.
| SKU | Diameter | Design Wavelength Range | Rotation Angle | Wavelength | Reflectivity, % | |
|---|---|---|---|---|---|---|
| 470-4044 | 20 mm | 400 nm - 400 nm | 45 Deg | 400 nm - 400 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4049 | 20 mm | 400 nm - 400 nm | 90 Deg | 400 nm - 400 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4244 | 20 mm | 244 nm - 244 nm | 45 Deg | 244 nm - 244 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$339
|
| 470-4249 | 20 mm | 244 nm - 244 nm | 90 Deg | 244 nm - 244 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$339
|
| 470-4254 | 20 mm | 257 nm - 257 nm | 45 Deg | 250 nm - 265 nm | 0 % - 0.2 % |
Out of stock
Ships in: 58–61 calendar days
$339
|
| 470-4259 | 20 mm | 257 nm - 257 nm | 90 Deg | 250 nm - 265 nm | 0 % - 0.2 % |
2 in stock
Ships in: 2–5 calendar days
$339
|
| 470-4264 | 20 mm | 266 nm - 266 nm | 45 Deg | 266 nm - 266 nm | 0 % - 0.2 % |
2 in stock
Ships in: 2–5 calendar days
$339
|
| 470-4269 | 20 mm | 266 nm - 266 nm | 90 Deg | 266 nm - 266 nm | 0 % - 0.2 % |
1 in stock
Ships in: 2–5 calendar days
$339
|
| 470-4344 | 20 mm | 343 nm - 343 nm | 45 Deg | 343 nm - 343 nm | 0 % - 0.2 % |
Out of stock
Ships in: 58–61 calendar days
$269
|
| 470-4349 | 20 mm | 343 nm - 343 nm | 90 Deg | 343 nm - 343 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4354 | 20 mm | 355 nm - 355 nm | 45 Deg | 355 nm - 355 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4359 | 20 mm | 355 nm - 355 nm | 90 Deg | 355 nm - 355 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4414 | 20 mm | 413 nm - 413 nm | 45 Deg | 413 nm - 413 nm | 0 % - 0.2 % |
Out of stock
Ships in: 58–61 calendar days
$269
|
| 470-4419 | 20 mm | 413 nm - 413 nm | 90 Deg | 413 nm - 413 nm | 0 % - 0.2 % |
Out of stock
Ships in: 58–61 calendar days
$269
|
| 470-4514 | 20 mm | 515 nm - 515 nm | 45 Deg | 515 nm - 515 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4519 | 20 mm | 515 nm - 515 nm | 90 Deg | 515 nm - 515 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4534 | 20 mm | 532 nm - 532 nm | 45 Deg | 532 nm - 532 nm | 0 % - 0.2 % |
3 in stock
Ships in: 2–5 calendar days
$269
|
| 470-4539 | 20 mm | 532 nm - 532 nm | 90 Deg | 532 nm - 532 nm | 0 % - 0.2 % |
2 in stock
Ships in: 2–5 calendar days
$269
|
| 470-4634 | 20 mm | 633 nm - 633 nm | 45 Deg | 633 nm - 633 nm | 0 % - 0.2 % |
3 in stock
Ships in: 2–5 calendar days
$269
|
| 470-4639 | 20 mm | 633 nm - 633 nm | 90 Deg | 633 nm - 633 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4644 | 20 mm | 1064 nm - 1064 nm | 45 Deg | 1064 nm - 1064 nm | 0 % - 0.2 % |
6 in stock
Ships in: 2–5 calendar days
$297
|
| 470-4649 | 20 mm | 1064 nm - 1064 nm | 90 Deg | 1064 nm - 1064 nm | 0 % - 0.2 % |
6 in stock
Ships in: 2–5 calendar days
$297
|
| 470-4784 | 20 mm | 780 nm - 780 nm | 45 Deg | 780 nm - 780 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$269
|
| 470-4789 | 20 mm | 780 nm - 780 nm | 90 Deg | 780 nm - 780 nm | 0 % - 0.2 % |
2 in stock
Ships in: 2–5 calendar days
$269
|
| 470-4804 | 20 mm | 800 nm - 800 nm | 45 Deg | 760 nm - 840 nm | 0 % - 0.2 % |
2 in stock
Ships in: 2–5 calendar days
$269
|
| 470-4809 | 20 mm | 800 nm - 800 nm | 90 Deg | 760 nm - 840 nm | 0 % - 0.5 % |
1 in stock
Ships in: 2–5 calendar days
$269
|
| 470-4904 | 20 mm | 1030 nm - 1030 nm | 45 Deg | 1000 nm - 1060 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$297
|
| 470-4909 | 20 mm | 1030 nm - 1030 nm | 90 Deg | 1000 nm - 1060 nm | 0 % - 0.2 % |
Out of stock
Ships in: 62–65 calendar days
$297
|
We can make this for you
No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.
Specifications
| Shape Type | Round |
| Diameter | 20 mm |
| Mounted | True |
| Mount Outer Diameter | 25.4 mm |
| Mount Clear Aperture | 17 mm |
| Material Type | Crystalline Material |
| Material | Crystal Quartz |
| TWD, fringes @633 nm | -(0.2) |
| Parallelism, angle | 0 deg 0 min 0 sec - 0 deg 0 min 10 sec |
Surface 1
| Surface quality, MIL | 20-10 |
| Power and Irregularity, fringes @633 nm | 0(0.2) |
Surface 1, Wavelength 1
| Coating | AR |
| AOI (angle of incidence) | 0 deg 0 min 0 sec - 0 deg 0 min 0 sec |
Surface 2
| Surface quality, MIL | 20-10 |
| Power and Irregularity, fringes @633 nm | 0(0.2) |
Surface 2, Wavelength 1
| Coating | AR |
| Reflectivity, % | 0 % - 0.2 % |
| AOI (angle of incidence) | 0 deg 0 min 0 sec - 0 deg 0 min 0 sec |
Description
- Made of crystalline quartz
- Intended to rotate beam polarization plane strictly to an appropriate angle using the circular birefringent effect
As compared to a waveplate, a rotator has an intrinsic advantage of being independent of rotation around its own optical axis. It needs no adjustment, only to be installed normally to the incident radiation. A Polarization Plane Rotator is normally used for the specific wavelength. It is only slightly dependent on ambient temperature.
