Nd:YAG Laser Harmonic Separators

Nd:YAG Laser Harmonic Separators

Reflectance is higher than 99.5% for the wavelength of interest and transmittance is at least 90% for the rejected wavelengths. Offered on Ø 0.5 or 1 inch substrates of BK7 or UVFS with surface flatness λ/10; The rear… Read more →

From $125 Configure & order →

Volume discount

  • 5–9 units −5%
  • 10+ units −10%

Applied in your cart. Quantities of any variant of this product count together.

Configure & order — pick a catalog variant or configure your own

Product

Diameter 12.7 mm - 25.4 mm · 2 values Any mm
mm
Material Any

Surface 1, Wavelength 1

Wavelength 266 nm - 1064 nm · 4 values Any nm
nm
Reflectivity, % 99 % - 100 % · 2 values Any %
%
AOI (angle of incidence) Any deg;min;sec
deg;min;sec
39 catalog variants — refine the spec to narrow it down.
SKU Shape Type Diameter Material Surface Shape Coating Wavelength Reflectivity, % AOI (angle of incidence) Polarization
031-5100 Round 12.7 mm BK7 Plano HR 532 nm - 532 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$125
031-5105 Round 12.7 mm BK7 Plano HR 532 nm - 532 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$125
031-6500 Round 12.7 mm BK7 Plano HR 1064 nm - 1064 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$131
031-6505 Round 12.7 mm BK7 Plano HR 1064 nm - 1064 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$131
032-5100 Round 25.4 mm BK7 Plano HR 532 nm - 532 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$159
032-5105 Round 25.4 mm BK7 Plano HR 532 nm - 532 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
11 in stock Ships in: 2–5 calendar days
$159
032-6500 Round 25.4 mm BK7 Plano HR 1064 nm - 1064 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec —
6 in stock Ships in: 2–5 calendar days
$166
032-6505 Round 25.4 mm BK7 Plano HR 1064 nm - 1064 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
3 in stock Ships in: 2–5 calendar days
$166
041-2310 Round 12.7 mm UVFS Plano HR 266 nm - 266 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec —
4 in stock Ships in: 2–5 calendar days
$214
041-2315 Round 12.7 mm UVFS Plano HR 266 nm - 266 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$214
041-2505 Round 12.7 mm UVFS Plano HR 266 nm - 266 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
11 in stock Ships in: 2–5 calendar days
$186
041-3100 Round 12.7 mm FS Plano HR 355 nm - 355 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
3 in stock Ships in: 2–5 calendar days
$159
041-3105 Round 12.7 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$159
041-3500 Round 12.7 mm FS Plano HR 355 nm - 355 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$159
041-3505 Round 12.7 mm FS Plano HR 355 nm - 355 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$159
041-3510 Round 12.7 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
2 in stock Ships in: 2–5 calendar days
$173
041-3515 Round 12.7 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
17 in stock Ships in: 2–5 calendar days
$173
041-5100 Round 12.7 mm UVFS Plano HR 532 nm - 532 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
9 in stock Ships in: 2–5 calendar days
$159
041-5105 Round 12.7 mm UVFS Plano HR 532 nm - 532 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
2 in stock Ships in: 2–5 calendar days
$159
041-5140 Round 12.7 mm UVFS Plano HR 532 nm - 532 nm 99 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec —
5 in stock Ships in: 2–5 calendar days
$284
041-5145 Round 12.7 mm UVFS Plano HR 532 nm - 532 nm 99 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
18 in stock Ships in: 2–5 calendar days
$284
041-6500 Round 12.7 mm UVFS Plano HR 1064 nm - 1064 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
1 in stock Ships in: 2–5 calendar days
$166
041-6505 Round 12.7 mm UVFS Plano HR 1064 nm - 1064 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
29 in stock Ships in: 2–5 calendar days
$166
042-2310 Round 25.4 mm UVFS Plano HR 266 nm - 266 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec —
5 in stock Ships in: 2–5 calendar days
$256
042-2315 Round 25.4 mm UVFS Plano HR 266 nm - 266 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
22 in stock Ships in: 2–5 calendar days
$256
042-2500 Round 25.4 mm UVFS Plano HR 266 nm - 266 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec —
2 in stock Ships in: 2–5 calendar days
$228
042-2505 Round 25.4 mm UVFS Plano HR 266 nm - 266 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
37 in stock Ships in: 2–5 calendar days
$228
042-3100 Round 25.4 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
4 in stock Ships in: 2–5 calendar days
$201
042-3105 Round 25.4 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$201
042-3500 Round 25.4 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec —
4 in stock Ships in: 2–5 calendar days
$201
042-3505 Round 25.4 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
9 in stock Ships in: 2–5 calendar days
$201
042-3510 Round 25.4 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$214
042-3515 Round 25.4 mm UVFS Plano HR 355 nm - 355 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
111 in stock Ships in: 2–5 calendar days
$214
042-5100 Round 25.4 mm UVFS Plano HR 532 nm - 532 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
4 in stock Ships in: 2–5 calendar days
$201
042-5105 Round 25.4 mm UVFS Plano HR 532 nm - 532 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
31 in stock Ships in: 2–5 calendar days
$201
042-5140 Round 25.4 mm UVFS Plano HR 532 nm - 532 nm 99 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec —
2 in stock Ships in: 2–5 calendar days
$318
042-5145 Round 25.4 mm UVFS Plano HR 532 nm - 532 nm 99 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
5 in stock Ships in: 2–5 calendar days
$318
042-6500 Round 25.4 mm UVFS Plano HR 1064 nm - 1064 nm 99.5 % - 100 % 0 deg 0 min 0 sec - 0 deg 0 min 0 sec avg
3 in stock Ships in: 2–5 calendar days
$208
042-6505 Round 25.4 mm UVFS Plano HR 1064 nm - 1064 nm 99.5 % - 100 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
16 in stock Ships in: 2–5 calendar days
$208

We can make this for you

No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.

Specifications

Shape Type Round
Diameter Upper Tolerance 0 mm
Diameter Lower Tolerance -0.12 mm
Parallelism, angle 0 deg 0 min 0 sec - 0 deg 0 min 30 sec

Surface 1

Surface Shape Plano
Surface quality, grind or polish Polished
Power and Irregularity, fringes @633 nm 0(0.2)
Clear Aperture, % 85 % - 100 %

Surface 1, Wavelength 1

Coating HR

Surface 2

Surface Shape Plano
Surface quality, grind or polish Polished
Power and Irregularity, fringes @633 nm 0(0.2)
Clear Aperture, % 85 % - 100 %

Surface 2, Wavelength 1

Coating AR

Description

Reflectance is higher than 99.5% for the wavelength of interest and transmittance is at least 90% for the rejected wavelengths. Offered on Ø 0.5 or 1 inch substrates of BK7 or UVFS with surface flatness λ/10; The rear surface of harmonic separators is antireflection coated.

Downloads

PDF
EKSMA_Optics_Laser_Harmonic_Separators_Nd-YAG_1_.pdf PDF · 133 KB
