Nd:YAG Laser Dual Band Mirrors
Dual Laser Line Mirrors are made of high quality BK7 or UV Fused Silica. The mirrors are designed for 45° or 0° angle of incidence. Featuring high polishing quality, low scattering and high damage threshold enables… Read more →
Volume discount
- 5–9 units −5%
- 10+ units −10%
Applied in your cart. Quantities of any variant of this product count together.
Order
| SKU | Shape Type | Diameter | Material | Surface Shape | Coating | Wavelength | Reflectivity, % | AOI (angle of incidence) | Polarization | |
|---|---|---|---|---|---|---|---|---|---|---|
| 067-3553 | Round | 76.2 mm | UVFS | Plano | HR | 355 nm - 355 nm | 99.5 % - 100 % | 45 deg 0 min 0 sec - 45 deg 0 min 0 sec | avg |
7 in stock
Ships in: 2–5 calendar days
$474
|
Specifications
| Shape Type | Round |
| Diameter | 76.2 mm |
| Diameter Upper Tolerance | 0 mm |
| Diameter Lower Tolerance | -0.12 mm |
| Center Thickness | 12.7 mm |
| Center Thickness Upper Tolerance | 0.25 mm |
| Center Thickness Lower Tolerance | -0.25 mm |
| Material Type | FS |
| Material | UVFS |
| Parallelism, angle | 0 deg 0 min 0 sec - 0 deg 0 min 3 sec |
Surface 1
| Surface Shape | Plano |
| Surface quality, grind or polish | Polished |
| Power and Irregularity, fringes @633 nm | 0(0.2) |
| Clear Aperture, % | 85 % - 100 % |
Surface 1, Wavelength 1
| Coating | HR |
| Wavelength | 355 nm - 355 nm |
| Reflectivity, % | 99.5 % - 100 % |
| AOI (angle of incidence) | 45 deg 0 min 0 sec - 45 deg 0 min 0 sec |
| Polarization | avg |
Surface 2
| Surface Shape | Plano |
| Surface quality, grind or polish | Polished |
| Power and Irregularity, fringes @633 nm | 0(0.2) |
Description
Dual Laser Line Mirrors are made of high quality BK7 or UV Fused Silica. The mirrors are designed for 45° or 0° angle of incidence. Featuring high polishing quality, low scattering and high damage threshold enables dielectric reflectors to have perfect beam steering for Nd:YAG lasers.
