Motorized Vertical Lift Stage 940-0220 SKU: 940-0220
• Compact • Stiff and stable • Two optical limit switches • Clean room grease Motorized Vertical Lift Stage 940-0220 offers precise vertical translation for elevating object up to 8 kg. An optional 1000-line rotary encoder is available for the stepper motor.
Shared product specifications
These specifications apply across the Motorized Vertical Lift Stage 940-0220 product family.
| Travel range | 5 mm |
| Resolution in full step | 0.625 μm |
| in 1 / 8 step | 0.078 μm |
| Lead screw pitch | 0.5 mm |
| Wedge reduction rate | 4:1 |
| Repeatability | 3 μm |
| Accuracy | 10 μm |
| Lift parallelism (to the base) | 20 μm |
| Mounting surface flatness | 10 μm |
| Position stability (max) | 3 μm |
| Maximum speed | 2.5 mm / s |
| Maximum load capacity | 8 kg |
| Limit switches | optoelectronic couple |
| Motor connector | DB9(M) |
| Stepper motor | 4247 |
