Motorized Vertical Lift Stage 940-0220
• Compact • Stiff and stable • Two optical limit switches • Clean room grease Motorized Vertical Lift Stage 940-0220 offers precise vertical translation for elevating object up to 8 kg. An optional 1000-line rotary… Read more →
Listed in
Order
| SKU | Spec | |
|---|---|---|
| 940-0220 |
Out of stock
$1,906
|
Specifications
| Travel range | 5 mm |
| Resolution in full step | 0.625 μm |
| in 1 / 8 step | 0.078 μm |
| Lead screw pitch | 0.5 mm |
| Wedge reduction rate | 4:1 |
| Repeatability | 3 μm |
| Accuracy | 10 μm |
| Lift parallelism (to the base) | 20 μm |
| Mounting surface flatness | 10 μm |
| Position stability (max) | 3 μm |
| Maximum speed | 2.5 mm / s |
| Maximum load capacity | 8 kg |
| Limit switches | optoelectronic couple |
| Motor connector | DB9(M) |
| Stepper motor | 4247 |
Description
- Compact
- Stiff and stable
- Two optical limit switches
- Clean room grease
Motorized Vertical Lift Stage 940-0220 offers precise vertical translation for elevating object up to 8 kg. An optional 1000-line rotary encoder is available for the stepper motor.
