Zero Order Air-Spaced Wave Plates SKU: 464-4241
• For high power laser application. This Zero Order Air-Spaced Plate, made of single crystal quartz.
Variant specifications
| Specification | Value |
|---|---|
| Center wavelength | 343 nm |
| AR coating range | 333-353 nm |
| Retardation | λ/2 |
| Clear aperture | Ø 17 mm |
| Mount | Ø 25.4 mm |
| Group | Retardation λ/2 |
Shared product specifications
These specifications apply across the Zero Order Air-Spaced Wave Plates product family.
| Material | Single crystal quartz |
| Optical axis | normal to facet on circumference of retarder |
| Wavefront distortion | λ / 10@633 nm |
| Surface quality | 20-10 scratch & dig (MIL-PRF-13830B) |
| Parallelism | <10 arcsec |
| AR coating | R<0.5% |
| Laser Damage Threshold | >10J / cm², 10 nsec pulse, 1064nm typical |
