Nd:YAG Laser Beamsplitters

Nd:YAG Laser Beamsplitters

This Beamsplitter splits average polarized laser beam into two beams separated by 90° from each other. It is designed for average polarization: R=(Rs+Rp)/2 and T=(Ts+Tp)/2

From $101 Configure & order →

Volume discount

  • 5–9 units −5%
  • 10+ units −10%

Applied in your cart. Quantities of any variant of this product count together.

Configure & order — pick a catalog variant or configure your own

Product

Diameter 12.7 mm - 25.4 mm · 2 values Any mm
mm
Material Any

Surface 1, Wavelength 1

Wavelength 266 nm - 1064 nm · 4 values Any nm
nm
Reflectivity, % 17 % - 93 % · 8 values Any %
%
Polarization Any
100 catalog variants — refine the spec to narrow it down.
SKU Shape Type Diameter Material Surface Shape Coating Wavelength Reflectivity, % AOI (angle of incidence) Polarization
031-7120A Round 12.7 mm BK7 Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
4 in stock Ships in: 2–5 calendar days
$104
031-7170A Round 12.7 mm BK7 Plano PR 1064 nm - 1064 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$104
031-7180A Round 12.7 mm BK7 Plano PR 1064 nm - 1064 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$104
031-7180P Round 12.7 mm BK7 Plano PR 1064 nm - 1064 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
Out of stock Ships in: 62–65 calendar days
$104
031-7230S Round 12.7 mm BK7 Plano PR 532 nm - 532 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 58–61 calendar days
$101
031-7250S Round 12.7 mm BK7 Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$101
031-7270P Round 12.7 mm BK7 Plano PR 532 nm - 532 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
Out of stock Ships in: 62–65 calendar days
$101
031-7280P Round 12.7 mm BK7 Plano PR 532 nm - 532 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
Out of stock Ships in: 62–65 calendar days
$101
032-7120A Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
3 in stock Ships in: 2–5 calendar days
$131
032-7120P Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
3 in stock Ships in: 2–5 calendar days
$131
032-7120S Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
1 in stock Ships in: 2–5 calendar days
$131
032-7130P Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
4 in stock Ships in: 2–5 calendar days
$131
032-7130S Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$131
032-7150A Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
1 in stock Ships in: 2–5 calendar days
$131
032-7150P Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
22 in stock Ships in: 2–5 calendar days
$131
032-7150S Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 50 % - 50 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$131
032-7175A Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 72 % - 78 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 58–61 calendar days
$131
032-7180A Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
6 in stock Ships in: 2–5 calendar days
$131
032-7190A Round 25.4 mm BK7 Plano PR 1064 nm - 1064 nm 87 % - 93 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 58–61 calendar days
$131
032-7220A Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
4 in stock Ships in: 2–5 calendar days
$129
032-7220P Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
3 in stock Ships in: 2–5 calendar days
$129
032-7220S Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
6 in stock Ships in: 2–5 calendar days
$129
032-7230A Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$129
032-7230P Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
1 in stock Ships in: 2–5 calendar days
$129
032-7230S Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$129
032-7250A Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$129
032-7250P Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
1 in stock Ships in: 2–5 calendar days
$129
032-7250S Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$129
032-7270A Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
5 in stock Ships in: 2–5 calendar days
$129
032-7270P Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
2 in stock Ships in: 2–5 calendar days
$129
032-7270S Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
4 in stock Ships in: 2–5 calendar days
$129
032-7280A Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
7 in stock Ships in: 2–5 calendar days
$129
032-7280P Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
5 in stock Ships in: 2–5 calendar days
$129
032-7280S Round 25.4 mm BK7 Plano PR 532 nm - 532 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
3 in stock Ships in: 2–5 calendar days
$129
041-7120A Round 12.7 mm UVFS Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
10 in stock Ships in: 2–5 calendar days
$131
041-7120S Round 12.7 mm FS Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$131
041-7150A Round 12.7 mm UVFS Plano PR 1064 nm - 1064 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$131
041-7150P Round 12.7 mm UVFS Plano PR 1064 nm - 1064 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
5 in stock Ships in: 2–5 calendar days
$131
041-7150S Round 12.7 mm FS Plano PR 1064 nm - 1064 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
5 in stock Ships in: 2–5 calendar days
$131
041-7220S Round 12.7 mm UVFS Plano PR 532 nm - 532 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$129
041-7230S Round 12.7 mm UVFS Plano PR 532 nm - 532 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
11 in stock Ships in: 2–5 calendar days
$129
041-7250A Round 12.7 mm UVFS Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
6 in stock Ships in: 2–5 calendar days
$129
041-7250S Round 12.7 mm UVFS Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
3 in stock Ships in: 2–5 calendar days
$129
041-7350A Round 12.7 mm FS Plano PR 355 nm - 355 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$146
042-7120A Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
6 in stock Ships in: 2–5 calendar days
$159
042-7120P Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
Out of stock Ships in: 62–65 calendar days
$159
042-7120S Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
8 in stock Ships in: 2–5 calendar days
$159
042-7130A Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$159
042-7130P Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
3 in stock Ships in: 2–5 calendar days
$159
042-7130S Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
3 in stock Ships in: 2–5 calendar days
$159
042-7150A Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
20 in stock Ships in: 2–5 calendar days
$159
042-7150P Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
6 in stock Ships in: 2–5 calendar days
$159
042-7150S Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$159
042-7170P Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
2 in stock Ships in: 2–5 calendar days
$159
042-7170S Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
1 in stock Ships in: 2–5 calendar days
$159
042-7175A Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 72 % - 78 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
3 in stock Ships in: 2–5 calendar days
$159
042-7180A Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$159
042-7180P Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
8 in stock Ships in: 2–5 calendar days
$159
042-7180S Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
3 in stock Ships in: 2–5 calendar days
$159
042-7190A Round 25.4 mm UVFS Plano PR 1064 nm - 1064 nm 87 % - 93 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$159
042-7220A Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
1 in stock Ships in: 2–5 calendar days
$156
042-7220P Round 25.4 mm FS Plano PR 532 nm - 532 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
Out of stock Ships in: 62–65 calendar days
$156
042-7220S Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
5 in stock Ships in: 2–5 calendar days
$156
042-7230A Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
3 in stock Ships in: 2–5 calendar days
$156
042-7230S Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
8 in stock Ships in: 2–5 calendar days
$156
042-7250A Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
3 in stock Ships in: 2–5 calendar days
$156
042-7250P Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
6 in stock Ships in: 2–5 calendar days
$156
042-7250S Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$156
042-7270A Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$156
042-7270P Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
6 in stock Ships in: 2–5 calendar days
$156
042-7270S Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
6 in stock Ships in: 2–5 calendar days
$156
042-7280A Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$156
042-7280P Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
Out of stock Ships in: 62–65 calendar days
$156
042-7280S Round 25.4 mm UVFS Plano PR 532 nm - 532 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
2 in stock Ships in: 2–5 calendar days
$156
042-7320A Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
5 in stock Ships in: 2–5 calendar days
$186
042-7320P Round 25.4 mm FS Plano PR 355 nm - 355 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
4 in stock Ships in: 2–5 calendar days
$186
042-7320S Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$186
042-7330A Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$186
042-7330P Round 25.4 mm FS Plano PR 355 nm - 355 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
6 in stock Ships in: 2–5 calendar days
$186
042-7330S Round 25.4 mm FS Plano PR 355 nm - 355 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$186
042-7350A Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
8 in stock Ships in: 2–5 calendar days
$186
042-7350P Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
1 in stock Ships in: 2–5 calendar days
$186
042-7350S Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
Out of stock Ships in: 62–65 calendar days
$186
042-7370A Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
1 in stock Ships in: 2–5 calendar days
$186
042-7370P Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
2 in stock Ships in: 2–5 calendar days
$186
042-7370S Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
5 in stock Ships in: 2–5 calendar days
$186
042-7380A Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
Out of stock Ships in: 62–65 calendar days
$186
042-7380P Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
3 in stock Ships in: 2–5 calendar days
$186
042-7380S Round 25.4 mm UVFS Plano PR 355 nm - 355 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
2 in stock Ships in: 2–5 calendar days
$186
042-7920A Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
7 in stock Ships in: 2–5 calendar days
$201
042-7920P Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 17 % - 23 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
7 in stock Ships in: 2–5 calendar days
$201
042-7930A Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
9 in stock Ships in: 2–5 calendar days
$201
042-7930P Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 27 % - 33 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
8 in stock Ships in: 2–5 calendar days
$201
042-7950A Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
7 in stock Ships in: 2–5 calendar days
$201
042-7950P Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
7 in stock Ships in: 2–5 calendar days
$201
042-7950S Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 47 % - 53 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
4 in stock Ships in: 2–5 calendar days
$201
042-7970P Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
Out of stock Ships in: 62–65 calendar days
$201
042-7970S Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 67 % - 73 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec s
8 in stock Ships in: 2–5 calendar days
$201
042-7980A Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec avg
3 in stock Ships in: 2–5 calendar days
$201
042-7980P Round 25.4 mm UVFS Plano PR 266 nm - 266 nm 77 % - 83 % 45 deg 0 min 0 sec - 45 deg 0 min 0 sec p
Out of stock Ships in: 62–65 calendar days
$201

We can make this for you

No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.

Specifications

Shape Type Round
Parallelism, angle 0 deg 0 min 0 sec - 0 deg 0 min 30 sec

Surface 1

Surface Shape Plano
Surface quality, grind or polish Polished
Power and Irregularity, fringes @633 nm 0(0.2)

Surface 1, Wavelength 1

Coating PR
AOI (angle of incidence) 45 deg 0 min 0 sec - 45 deg 0 min 0 sec

Surface 2

Surface Shape Plano
Surface quality, grind or polish Polished
Power and Irregularity, fringes @633 nm 0(0.2)

Surface 2, Wavelength 1

Coating AR
AOI (angle of incidence) 45 deg 0 min 0 sec - 45 deg 0 min 0 sec

Description

This Beamsplitter splits average polarized laser beam into two beams separated by 90° from each other. It is designed for average polarization: R=(Rs+Rp)/2 and T=(Ts+Tp)/2

Downloads

PDF
EKSMA_Optics_Laser_Beamsplitters-Nd-YAG.pdf PDF · 104 KB

Related products — often paired with this product
