Laser Line Mirrors on N-BK7 substrate

Laser Line Mirrors on N-BK7 substrate

• Highly reflective mirrors (>99.5% reflectivity) • Designed to work at 45° or 0° angle of incidence • Made from BK7 optical substrate • Recommended as a low-cost alternative to UV FS mirrors for non-critical laser… Read more →

From $75 Configure & order →

Volume discount

  • 5–9 units −5%
  • 10+ units −10%

Applied in your cart. Quantities of any variant of this product count together.

Listed in

Configure & order — pick a catalog variant or configure your own

D Any
Catalog band: 12.7–76.2 mm
Manufacturable: 12.7–76.2 mm
12.7 mm 76.2 mm
or mm
ET Any
Catalog band: 3.0–12.7 mm
Manufacturable: 3.0–12.7 mm
3.0 mm 12.7 mm
or mm
R, % (s+p)/2 Any
Catalog band: 99.5–99.8 %
Manufacturable: 99.5–99.8 %
99.5 % 99.8 %
or %
AOI Any
Catalog band: 0.0–45.0 °
Manufacturable: 0.0–45.0 °
0.0 ° 45.0 °
or °
Wavelength Any
or
Application Any
or
R, % (S+p)/2 Any
Catalog band: 99.5–99.8 %
Manufacturable: 99.5–99.8 %
99.5 % 99.8 %
or %
138 catalog variants — refine the spec to narrow it down.
SKU Wavelength · Application · Group · D · ET · R, % (s+p)/2 · AOI · Thickness · R, % (S+p)/2 · Material · Diameter
031-0350 351-361 nm·Nd:YAG 3H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
Out of stock Ships in: 62–65 calendar days
$78
031-0350-i0 351-361 nm·YAG 3H·99.7%·0°·3 mm·BK7·ø 12.7 mm
Out of stock Ships in: 58–61 calendar days
$78
031-0350T6 351-361 nm·Nd:YAG 3H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.5%·45°
3 in stock Ships in: 2–5 calendar days
$78
031-0350T6-i0 351-361 nm·YAG 3H·99.7%·0°·6 mm·BK7·ø 12.7 mm
Out of stock Ships in: 58–61 calendar days
$78
031-0400 380-420 nm·Ti:Sa 2H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
6 in stock Ships in: 2–5 calendar days
$76
031-0400T6 380-420 nm·Ti:Sa 2H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.5%·45°
1 in stock Ships in: 2–5 calendar days
$76
031-0400T6-i0 380-420 nm·Ti:Sa 2H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.8%·0°
6 in stock Ships in: 2–5 calendar days
$76
031-0442 442 nm·HeCd·12.7 mm·3 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$76
031-0442-i0 442 nm·HeCd·12.7 mm·3 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$76
031-0442T6 442 nm·HeCd·12.7 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$76
031-0442T6-i0 442 nm·HeCd·12.7 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$76
031-0490 488-515 nm·Ar+·12.7 mm·3 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$76
031-0490-i0 488-515 nm·Ar+·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$76
031-0490T6 488-515 nm·Ar+·12.7 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$76
031-0490T6-i0 488-515 nm·Ar+·12.7 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$76
031-0515 500-530 nm·Yb:KGW/KYW 2H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
23 in stock Ships in: 2–5 calendar days
$75
031-0515-i0 500-530 nm·Yb:KGW/KYW 2H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
7 in stock Ships in: 2–5 calendar days
$75
031-0515T6 500-530 nm·Yb:KGW/KYW 2H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.5%·45°
4 in stock Ships in: 2–5 calendar days
$75
031-0515T6-i0 500-530 nm·Yb:KGW/KYW 2H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$75
031-0530 527-532 nm·Nd:YAG 2H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
1 in stock Ships in: 2–5 calendar days
$75
031-0530-i0 527-532 nm·Nd:YAG 2H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$75
031-0530T6 527-532 nm·Nd:YAG 2H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.5%·45°
16 in stock Ships in: 2–5 calendar days
$75
031-0530T6-i0 527-532 nm·YAG 2H·99.7%·0°·6 mm·BK7·ø 12.7 mm
Out of stock Ships in: 58–61 calendar days
$75
031-0590 589 nm·Dye·12.7 mm·3 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$75
031-0590-i0 589 nm·Dye·12.7 mm·3 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$75
031-0590T6 589 nm·Dye·12.7 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$75
031-0590T6-i0 589 nm·Dye·12.7 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$75
031-0630 633-670 nm·HeNe+Diode·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
2 in stock Ships in: 2–5 calendar days
$75
031-0630-i0 633-670 nm·HeNe+Diode·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
12 in stock Ships in: 2–5 calendar days
$75
031-0630T6 633-670 nm·HeNe+Diode·12.7 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$75
031-0630T6-i0 633-670 nm·HeNe+Diode·12.7 mm·6 mm·0°·99.8%
3 in stock Ships in: 2–5 calendar days
$75
031-0694 694 nm·Ruby·12.7 mm·3 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$75
031-0694-i0 694 nm·Ruby·12.7 mm·3 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$75
031-0694T6 694 nm·Ruby·12.7 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$75
031-0694T6-i0 694 nm·Ruby·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$75
031-0780 780 nm·Diode·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
Out of stock Ships in: 62–65 calendar days
$76
031-0780-i0 780 nm·Diode·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$76
031-0780T6 780 nm·Diode·12.7 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$76
031-0780T6-i0 780 nm·Diode·12.7 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$76
031-0800 760-840 nm·Ti:Sa 1H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
9 in stock Ships in: 2–5 calendar days
$81
031-0800T6-i0 760-840 nm·Ti:Sa 1H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.8%·0°
3 in stock Ships in: 2–5 calendar days
$81
031-0850 852 nm·Diode·12.7 mm·3 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$76
031-0850-i0 852 nm·Diode·12.7 mm·3 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$76
031-0850T6 852 nm·Diode·12.7 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$76
031-0850T6-i0 852 nm·Diode·12.7 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$76
031-0980 980 nm·Diode·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
2 in stock Ships in: 2–5 calendar days
$76
031-0980-i0 980 nm·Diode·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$76
031-0980T6 980 nm·Diode·12.7 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$76
031-0980T6-i0 980 nm·Diode·12.7 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$76
031-1030-i0 1000-1060 nm·Yb:KGW/KYW 1H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
12 in stock Ships in: 2–5 calendar days
$76
031-1030T6 1000-1060 nm·Yb:KGW/KYW 1H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.5%·45°
51 in stock Ships in: 2–5 calendar days
$76
031-1030T6-i0 1000-1060 nm·Yb:KGW/KYW 1H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.8%·0°
13 in stock Ships in: 2–5 calendar days
$76
031-1060 1047-1064 nm·Nd:YAG 1H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
22 in stock Ships in: 2–5 calendar days
$76
031-1060-i0 1047-1064 nm·Nd:YAG 1H·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
15 in stock Ships in: 2–5 calendar days
$76
031-1060T6 1047-1064 nm·Nd:YAG 1H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.5%·45°
11 in stock Ships in: 2–5 calendar days
$76
031-1060T6-i0 1047-1064 nm·Nd:YAG 1H·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.8%·0°
5 in stock Ships in: 2–5 calendar days
$76
031-1300 1300-1320 nm·YAG·12.7 mm·3 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$81
031-1300-i0 1300-1320 nm·YAG·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$81
031-1300T6 1300-1320 nm·YAG·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.5%·45°
Out of stock Ships in: 62–65 calendar days
$81
031-1300T6-i0 1300-1320 nm·YAG·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.8%·0°
10 in stock Ships in: 2–5 calendar days
$81
031-1550 1520-1570 nm·Diode·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.5%·45°
7 in stock Ships in: 2–5 calendar days
$81
031-1550-i0 1520-1570 nm·Diode·BK7; ø12.7 x 3 mm·12.7 mm·3 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$81
031-1550T6 1520-1570 nm·Diode·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.5%·45°
18 in stock Ships in: 2–5 calendar days
$81
031-1550T6-i0 1520-1570 nm·Diode·BK7; ø12.7 x 6 mm·12.7 mm·6 mm·99.8%·0°
12 in stock Ships in: 2–5 calendar days
$81
032-0350 351-361 nm·Nd:YAG 3H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
15 in stock Ships in: 2–5 calendar days
$119
032-0350-i0 351-361 nm·Nd:YAG 3H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
2 in stock Ships in: 2–5 calendar days
$119
032-0400 380-420 nm·Ti:Sa 2H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
30 in stock Ships in: 2–5 calendar days
$118
032-0400-i0 380-420 nm·Ti:Sa 2H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
23 in stock Ships in: 2–5 calendar days
$118
032-0442 442 nm·HeCd·25.4 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$110
032-0442-i0 442 nm·HeCd·25.4 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$110
032-0490 488-515 nm·Ar+·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
4 in stock Ships in: 2–5 calendar days
$110
032-0490-i0 488-515 nm·Ar+·25.4 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$110
032-0515 500-530 nm·Yb:KGW/KYW 2H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
2 in stock Ships in: 2–5 calendar days
$98
032-0515-i0 500-530 nm·Yb:KGW/KYW 2H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
15 in stock Ships in: 2–5 calendar days
$98
032-0530 527-532 nm·Nd:YAG 2H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
66 in stock Ships in: 2–5 calendar days
$98
032-0530-i0 527-532 nm·Nd:YAG 2H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$98
032-0590 589 nm·Dye·25.4 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$108
032-0590-i0 589 nm·Dye·25.4 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$108
032-0630 633-670 nm·HeNe+Diode·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
12 in stock Ships in: 2–5 calendar days
$100
032-0630-i0 633-670 nm·HeNe+Diode·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
11 in stock Ships in: 2–5 calendar days
$100
032-0694 694 nm·Ruby·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
5 in stock Ships in: 2–5 calendar days
$100
032-0694-i0 694 nm·Ruby·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
4 in stock Ships in: 2–5 calendar days
$100
032-0780 780 nm·Diode·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
40 in stock Ships in: 2–5 calendar days
$110
032-0780-i0 780 nm·Diode·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
4 in stock Ships in: 2–5 calendar days
$110
032-0800 760-840 nm·Ti:Sa 1H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
6 in stock Ships in: 2–5 calendar days
$113
032-0800-i0 760-840 nm·Ti:Sa 1H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
18 in stock Ships in: 2–5 calendar days
$113
032-0850 852 nm·Diode·25.4 mm·6 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$110
032-0850-i0 852 nm·Diode·25.4 mm·6 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$110
032-0980 980 nm·Diode·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
26 in stock Ships in: 2–5 calendar days
$110
032-0980-i0 980 nm·Diode·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
3 in stock Ships in: 2–5 calendar days
$110
032-1030 1000-1060 nm·Yb:KGW/KYW 1H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
56 in stock Ships in: 2–5 calendar days
$100
032-1030-i0 1000-1060 nm·Yb:KGW/KYW 1H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
36 in stock Ships in: 2–5 calendar days
$100
032-1060 1047-1064 nm·Nd:YAG 1H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
71 in stock Ships in: 2–5 calendar days
$100
032-1060-i0 1047-1064 nm·Nd:YAG 1H·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
6 in stock Ships in: 2–5 calendar days
$100
032-1300 1300-1320 nm·YAG·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
12 in stock Ships in: 2–5 calendar days
$113
032-1300-i0 1300-1320 nm·YAG·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
11 in stock Ships in: 2–5 calendar days
$113
032-1550 1520-1570 nm·Diode·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.5%·45°
15 in stock Ships in: 2–5 calendar days
$119
032-1550-i0 1520-1570 nm·Diode·BK7; ø25.4 x 6 mm·25.4 mm·6 mm·99.8%·0°
17 in stock Ships in: 2–5 calendar days
$119
035-0350 351-361 nm·Nd:YAG 3H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
Out of stock Ships in: 62–65 calendar days
$170
035-0350-i0 351-361 nm·Nd:YAG 3H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
3 in stock Ships in: 2–5 calendar days
$170
035-0400 380-420 nm·Ti:Sa 2H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
6 in stock Ships in: 2–5 calendar days
$176
035-0400-i0 380-420 nm·Ti:Sa 2H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
2 in stock Ships in: 2–5 calendar days
$176
035-0442 442 nm·HeCd·50.8 mm·8 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$176
035-0442-i0 442 nm·HeCd·50.8 mm·8 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$176
035-0490 488-515 nm·Ar+·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
Out of stock Ships in: 62–65 calendar days
$176
035-0490-i0 488-515 nm·Ar+·50.8 mm·8 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$176
035-0515 500-530 nm·Yb:KGW/KYW 2H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
Out of stock Ships in: 62–65 calendar days
$146
035-0515-i0 500-530 nm·Yb:KGW/KYW 2H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
1 in stock Ships in: 2–5 calendar days
$146
035-0530 527-532 nm·Nd:YAG 2H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
4 in stock Ships in: 2–5 calendar days
$146
035-0530-i0 527-532 nm·Nd:YAG 2H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
2 in stock Ships in: 2–5 calendar days
$146
035-0590 589 nm·Dye·50.8 mm·8 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$161
035-0590-i0 589 nm·Dye·50.8 mm·8 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$161
035-0630 633-670 nm·HeNe+Diode·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
1 in stock Ships in: 2–5 calendar days
$161
035-0630-i0 633-670 nm·HeNe+Diode·50.8 mm·8 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$161
035-0694 694 nm·Ruby·50.8 mm·8 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$161
035-0694-i0 694 nm·Ruby·50.8 mm·8 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$161
035-0780 780 nm·Diode·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
3 in stock Ships in: 2–5 calendar days
$161
035-0780-i0 780 nm·Diode·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
2 in stock Ships in: 2–5 calendar days
$161
035-0800 760-840 nm·Ti:Sa 1H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
28 in stock Ships in: 2–5 calendar days
$176
035-0800-i0 760-840 nm·Ti:Sa 1H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
5 in stock Ships in: 2–5 calendar days
$176
035-0850 852 nm·Diode·50.8 mm·8 mm·45°·99.5%
Out of stock Ships in: 58–61 calendar days
$160
035-0850-i0 852 nm·Diode·50.8 mm·8 mm·0°·99.8%
Out of stock Ships in: 58–61 calendar days
$160
035-0980 980 nm·Diode·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
3 in stock Ships in: 2–5 calendar days
$161
035-0980-i0 980 nm·Diode·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$161
035-1030 1000-1060 nm·Yb:KGW/KYW 1H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
1 in stock Ships in: 2–5 calendar days
$146
035-1030-i0 1000-1060 nm·Yb:KGW/KYW 1H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
9 in stock Ships in: 2–5 calendar days
$146
035-1060 1047-1064 nm·Nd:YAG 1H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
5 in stock Ships in: 2–5 calendar days
$146
035-1060-i0 1047-1064 nm·Nd:YAG 1H·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
8 in stock Ships in: 2–5 calendar days
$146
035-1300 1300-1320 nm·YAG·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
2 in stock Ships in: 2–5 calendar days
$182
035-1300-i0 1300-1320 nm·YAG·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
2 in stock Ships in: 2–5 calendar days
$182
035-1550 1520-1570 nm·Diode·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.5%·45°
5 in stock Ships in: 2–5 calendar days
$184
035-1550-i0 1520-1570 nm·Diode·BK7; ø50.8 x 8 mm·50.8 mm·8 mm·99.8%·0°
3 in stock Ships in: 2–5 calendar days
$184
037-0400 380-420 nm·Ti:Sa 2H·BK7; ø76.2 x 12.7 mm·76.2 mm·12.7 mm·99.5%·45°
Out of stock Ships in: 62–65 calendar days
$263
037-0530-i0 527-532 nm·Nd:YAG 2H·BK7; ø76.2 x 12.7 mm·76.2 mm·12.7 mm·99.8%·0°
1 in stock Ships in: 2–5 calendar days
$245
037-0800 760-840 nm·Ti:Sa 1H·BK7; ø76.2 x 12.7 mm·76.2 mm·12.7 mm·99.5%·45°
5 in stock Ships in: 2–5 calendar days
$263
037-0800-i0 760-840 nm·Ti:Sa 1H·BK7; ø76.2 x 12.7 mm·76.2 mm·12.7 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$263
037-1060 1047-1064 nm·Nd:YAG 1H·BK7; ø76.2 x 12.7 mm·76.2 mm·12.7 mm·99.5%·45°
1 in stock Ships in: 2–5 calendar days
$245
037-1060-i0 1047-1064 nm·Nd:YAG 1H·BK7; ø76.2 x 12.7 mm·76.2 mm·12.7 mm·99.8%·0°
Out of stock Ships in: 62–65 calendar days
$245

We can make this for you

No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.

Specifications

SUBSTRATE

Material BK7 grade A glass
S1 Surface Flatness λ / 10 typical at 633 nm
S1 Surface Quality 20-10 scratch & dig (MIL-PRF-13830B)
S2 Surface Quality Commercial polish
Diameter Tolerance + 0.00 mm, - 0.12 mm
Thickness Tolerance ± 0.25 mm
Wedge < 3 minutes
Chamfer 0.3 mm at 45° typical

COATING

Technology Electron beam multilayer dielectric
Adhesion and Durability Per MIL-C-675A. Insoluble in lab solvents
Clear Aperture Exceeds central 85% of diameter
Damage Threshold 6 J / cm², 8 nsec pulse, 1064 nm typical
Coated Surface Flatness λ / 10 at 633 nm over clear aperture
Angle of incidence 0° or 45°

Classification

Coating dielectric

Description

  • Highly reflective mirrors (>99.5% reflectivity)
  • Designed to work at 45° or 0° angle of incidence
  • Made from BK7 optical substrate
  • Recommended as a low-cost alternative to UV FS mirrors for non-critical laser applications
  • For laser line mirrors made of UV grade fused silica, please click here

Laser line mirrors are dielectric reflectors with an optimized performance at stated laser wavelengths. In this section we present laser mirrors made from BK7 glass and coated with a multilayer dielectric or IBS coating. High polishing quality of the mirror substrates is also important for low wave front distortion, low scattering and high damage threshold.

BK7 laser line mirors cover a wide range of laser applications in UV, VIS and NIR spectra.

Downloads

PDF
EKSMA_Optics_Laser_Mirrors_1_.pdf PDF · 207 KB

Related products — often paired with this product
