HVS100 High Voltage Power Supply
Laboratory type HVS100 series high voltage power supply is especially designed for powering of drivers of Pockels cells. However, it can also be used as a general-purpose high voltage power supply for other electronic… Read more →
Listed in
Configure & order — pick a catalog variant or configure your own
| SKU | Max HV output · Max output power | |
|---|---|---|
| HVS100-120-1.8 | 1.8 kV·120 W |
Out of stock
—
|
| HVS100-120-2.6 | 2.6 kV·120 W |
Out of stock
$3,416
|
| HVS100-120-3.1 | 3.1 kV·120 W |
Out of stock
—
|
| HVS100-120-3.6 | 3.6 kV·120 W |
Out of stock
—
|
| HVS100-150-1.8 | 1.8 kV·150 W |
Out of stock
$5,355
|
| HVS100-150-2.6 | 2.6 kV·150 W |
Out of stock
—
|
| HVS100-150-3.1 | 3.1 kV·150 W |
Out of stock
—
|
| HVS100-150-3.6 | 3.6 kV·150 W |
Out of stock
—
|
| HVS100-150-4.0 | 4.0 kV·150 W |
Out of stock
$5,355
|
| HVS100-150-4.4 | 4.4 kV·150 W |
Out of stock
—
|
| HVS100-2x120-1.8 | 1.8 kV·2x120 W |
Out of stock
$5,286
|
| HVS100-2x120-2.6 | 2.6 kV·2x120 W |
Out of stock
—
|
| HVS100-2x120-3.1 | 3.1 kV·2x120 W |
Out of stock
—
|
| HVS100-2x120-3.6 | 3.6 kV·2x120 W |
Out of stock
—
|
| HVS100-2x60-1.4 | +/- 1.4 kV·2x60 W |
Out of stock
$3,416
|
| HVS100-2x60-2.6 | +/- 2.6 kV·2x60 W |
Out of stock
$3,416
|
| HVS100-40-1.3 | 1.3 kV·40 W |
Out of stock
—
|
| HVS100-40-1.8 | 1.8 kV·40 W |
Out of stock
$3,059
|
| HVS100-40-2.5 | 2.5 kV·40 W |
Out of stock
$3,059
|
| HVS100-40-3.6 | 3.6 kV·40 W |
Out of stock
$3,059
|
| HVS100-40-4.0 | 4.0 kV·40 W |
Out of stock
$3,059
|
| HVS100-4x60-1.4 | 1.4 kV·4x60 W |
Out of stock
—
|
| HVS100-4x60-2.0 | +/- 2.0 kV·4x60 W |
Out of stock
$5,378
|
| HVS100-4x60-2.6 | 2.6 kV·4x60 W |
Out of stock
—
|
| HVS100-4x60-3.6 | +/- 3.6 kV·4x60 W |
Out of stock
$5,378
|
| HVS100-5-1.8 | 1.8 kV·5 W |
Out of stock
—
|
| HVS100-5-2.8 | 2.8 kV·5 W |
Out of stock
$2,978
|
| HVS100-5-4.0 | 4.0 kV·5 W |
Out of stock
—
|
| HVS100-5-4.4 | 4.4 kV·5 W |
Out of stock
$2,978
|
| HVS100-5-5.0 | 5.0 kV·5 W |
Out of stock
$2,978
|
| HVS100-80-1.8 | 1.8 kV·80 W |
Out of stock
$3,416
|
| HVS100-80-2.6 | 2.6 kV·80 W |
Out of stock
$3,416
|
| HVS100-80-3.1 | 3.1 kV·80 W |
Out of stock
$3,416
|
| HVS100-80-3.6 | 3.6 kV·80 W |
Out of stock
$3,416
|
| HVS100-80-4.0 | 4.0 kV·80 W |
Out of stock
—
|
| HVS100-80-4.4 | 4.4 kV·80 W |
Out of stock
—
|
We can make this for you
No catalog variant matches your exact spec. Add it to your cart as a quote request — sales will confirm price and lead time within 1 business day.
Specifications
| MODEL | HVS100-2x60 | HVS100-120 | HVS100-5 | HVS100-40 | HVS100-80 | HVS100-150 | HVS100-4x60 | HVS100-2x120 |
|---|---|---|---|---|---|---|---|---|
| Maximal high voltage output options | + / -1.4 kV / + / -2.6 kV | 1.8 kV / 2.6 kV / 3.1 kV / 3.6 kV | 1.8 kV / 2.8 kV / 4.0 kV / 4.4 kV / 5.0 kV | 1.3 kV / 1.8 kV / 2.5 kV / 3.6 kV / 4.0 kV | 1.8 kV / 2.6 kV / 3.1 kV / 3.6 kV / 4.0 kV | 1.8 kV / 2.6 kV / 3.1 kV / 3.6 kV / 4.0 kV | + / -1.4 kV / + / -2.0 kV / + / -2.6 kV / + / -3.6 kV | 1.8 kV / 2.6 kV / 3.1 kV / 3.6 kV |
| Maximal output power at maximal output voltage | 2 x 60 W | 120 W | 5 W | 40 W | 80 W | 150 W | 4 x 60 W | 2 x 120 W |
| Voltage control limits | 40% Umax to Umax | 40% Umax to Umax | 40% Umax to Umax | 40% Umax to Umax | 40% Umax to Umax | 40% Umax to Umax | 40% Umax to Umax | 40% Umax to Umax |
| Remaining power at the output of 24 V DC for external needs | 55 W | 55 W | 190 W | 150 W | 100 W | Not available | Not available | Not available |
| Mains voltage | 90 to 264 V AC, 47 - 63 Hz | 90 to 264 V AC, 47 - 63 Hz | 90 to 264 V AC, 47 - 63 Hz | 90 to 264 V AC, 47 - 63 Hz | 90 to 264 V AC, 47 - 63 Hz | 24 V DC¹⁾ | 24 V DC¹⁾ | 24 V DC¹⁾ |
| Dimensions (W x L x H) | 230 x 245 x 53.5 mm | 230 x 245 x 53.5 mm | 230 x 245 x 53.5 mm | 230 x 245 x 53.5 mm | 230 x 245 x 53.5 mm | 230 x 245 x 53.5 mm | 230 x 245 x 53.5 mm | 230 x 245 x 53.5 mm |
| Weight | 2.5 kg | 2.5 kg | 2.5 kg | 2.5 kg | 2.5 kg | 2.5 kg | 2.5 kg | 2.5 kg |
Description
Laboratory type HVS100 series high voltage power supply is especially designed for powering of drivers of Pockels cells. However, it can also be used as a general-purpose high voltage power supply for other electronic devices and different applications in the laboratory.
HVS100 features two voltage output channels – adjustable high voltage output channel and 24 V DC output channel. Required high voltage value can be set and adjusted in the limits from 40% of maximal specified voltage to maximal specified voltage (40% Umₐₓ to Umₐₓ).
HVS100 has 2.4-inch OLED display for high voltage control and current consumption monitoring at the output channel.
