Lithium Iodate – LiIO3 Crystals
Applications • Harmonic generators • Thin LiIO3 for autocorrelation measurements Eksma Optics offers: • The mass production of LiIO3 crystals • Attractive discounts for OEM customers • Different shapes (slabs,… Read more →
Volume discount
- 5–9 units −5%
- 10+ units −10%
Applied in your cart. Quantities of any variant of this product count together.
Configure & order — pick a catalog variant or configure your own
Product
Width
4 mm - 10 mm · 4 values
Any
mm
mm
Thickness
0.1 mm - 5 mm · 5 values
Any
mm
mm
Theta Angle
20.1 Deg - 36 Deg · 5 values
Any
Deg
Deg
Surface 1, Wavelength 1
Coating
Any
Wavelength
700 nm - 3000 nm · 5 values
Any
nm
nm
6
catalog variants — refine the spec to narrow it down.
| SKU | Width | Thickness | Product Type | Theta Angle | Coating | Wavelength | |
|---|---|---|---|---|---|---|---|
| LiIO3-0722-01 | 6 mm | 0.3 mm | T1 | 23 Deg | BBAR | 700 nm - 1800 nm |
Out of stock
Ships in: 62–65 calendar days
—
|
| LiIO3-1004-01 | 6 mm | 1 mm | T1 | 23 Deg | BBAR | 700 nm - 1800 nm |
Out of stock
Ships in: 62–65 calendar days
$648
|
| LiIO3-1105-01 | 5 mm | 5 mm | T1 | 36 Deg | BBAR | 700 nm - 1900 nm |
Out of stock
Ships in: 62–65 calendar days
$774
|
| LiIO3-1105-02 | 10 mm | 0.1 mm | T1 | 20.1 Deg | P | 700 nm - 900 nm |
Out of stock
Ships in: 62–65 calendar days
—
|
| LiIO3-1105-03H | 6 mm | 0.1 mm | T1 | 21.5 Deg | BBAR | 1500 nm - 3000 nm |
Out of stock
Ships in: 62–65 calendar days
$672
|
| LiIO3-1105-04 | 4 mm | 2 mm | T1 | 21 Deg | P | 800 nm - 1300 nm |
Out of stock
Ships in: 62–65 calendar days
—
|
We can make this for you
No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.
Specifications
| Material Type | Crystalline Material |
| Material | LiIO3 |
| Product Type | T1 |
| Theta Angle Tolerance | 0.5 Deg |
| Phi Angle | 0 Deg |
| Phi Angle Tolerance | 0.5 Deg |
| TWD, fringes @633 nm | -(0.5) |
| Parallelism, angle | 0 deg 0 min 0 sec - 0 deg 0 min 30 sec |
Surface 1
| Surface Shape | Plano |
| Surface quality, grind or polish | Polished |
| Power and Irregularity, fringes @633 nm | -(0.5) |
| Clear Aperture, % | 90 % - 100 % |
Surface 1, Wavelength 1
| AOI (angle of incidence) | 0 deg 0 min 0 sec - 0 deg 0 min 0 sec |
Surface 2
| Surface Shape | Plano |
| Surface quality, grind or polish | Polished |
| Power and Irregularity, fringes @633 nm | -(0.5) |
| Clear Aperture, % | 90 % - 100 % |
Surface 2, Wavelength 1
| AOI (angle of incidence) | 0 deg 0 min 0 sec - 0 deg 0 min 0 sec |
Side Surface 1
| Perpendicularity | 0 deg 0 min 0 sec - 0 deg 5 min 0 sec |
Description
Applications
- Harmonic generators
- Thin LiIO3 for autocorrelation measurements
Eksma Optics offers:
- The mass production of LiIO3 crystals
- Attractive discounts for OEM customers
- Different shapes (slabs, cylinders, Brewster ends) are available
- Standard open ring holders
- Recoating and repolishing service
- AR, BBAR and P - coatings subject to customer's choice
- P-coatings optimised at pump wavelengths
- BBAR coatings for wavelength tuned Ti:Sapphire and other lasers
