Laser Line Anti-Reflection Coated Precision Windows
• Made of high quality UV FS and BK7 • AR coated at 266 nm, 355 nm, 532 nm or 1064 nm Featuring high optical transmission with little distortion of the transmitted signal, precision windows are a good solution for… Read more →
Volume discount
- 5–9 units −5%
- 10+ units −10%
Applied in your cart. Quantities of any variant of this product count together.
Configure & order — pick a catalog variant or configure your own
Product
Diameter
12.7 mm - 50.8 mm · 4 values
Any
mm
mm
Thickness
3 mm - 12 mm · 5 values
Any
mm
mm
Material
Any
Surface 1, Wavelength 1
Wavelength
266 nm - 1064 nm · 4 values
Any
nm
nm
Surface 2, Wavelength 1
Wavelength
266 nm - 1064 nm · 4 values
Any
nm
nm
37
catalog variants — refine the spec to narrow it down.
| SKU | Diameter | Thickness | Material | Coating S1W1 | Wavelength S1W1 | Coating S2W1 | Wavelength S2W1 | |
|---|---|---|---|---|---|---|---|---|
| 221-0101E | 12.7 mm | 3 mm | BK7 | AR | 1064 nm | AR | 1064 nm |
10 in stock
Ships in: 2–5 calendar days
$62
|
| 221-0103E | 12.7 mm | 3 mm | BK7 | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$80
|
| 221-0201E | 25.4 mm | 6 mm | BK7 | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$74
|
| 221-0203E | 25.4 mm | 6 mm | BK7 | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$106
|
| 221-0402E | 38.1 mm | 8 mm | BK7 | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$104
|
| 221-0403E | 38.1 mm | 10 mm | BK7 | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$146
|
| 221-0502E | 50.8 mm | 10 mm | BK7 | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$119
|
| 221-0503E | 50.8 mm | 12 mm | BK7 | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$178
|
| 221-1101E | 12.7 mm | 3 mm | UVFS | AR | 1064 nm | AR | 1064 nm |
74 in stock
Ships in: 2–5 calendar days
$78
|
| 221-1103E | 12.7 mm | 3 mm | UVFS | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$99
|
| 221-1201E | 25.4 mm | 6 mm | UVFS | AR | 1064 nm | AR | 1064 nm |
70 in stock
Ships in: 2–5 calendar days
$84
|
| 221-1203E | 25.4 mm | 6 mm | UVFS | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$134
|
| 221-1402E | 38.1 mm | 8 mm | UVFS | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$152
|
| 221-1502E | 50.8 mm | 10 mm | UVFS | AR | 1064 nm | AR | 1064 nm |
1 in stock
Ships in: 2–5 calendar days
$212
|
| 221-1503E | 50.8 mm | 12 mm | UVFS | AR | 1064 nm | AR | 1064 nm |
Out of stock
Ships in: 62–65 calendar days
$255
|
| 222-0101E | 12.7 mm | 3 mm | BK7 | AR | 532 nm | AR | 532 nm |
Out of stock
Ships in: 62–65 calendar days
$62
|
| 222-0201E | 25.4 mm | 6 mm | BK7 | AR | 532 nm | AR | 532 nm |
Out of stock
Ships in: 62–65 calendar days
$74
|
| 222-0402E | 38.1 mm | 8 mm | BK7 | AR | 532 nm | AR | 532 nm |
1 in stock
Ships in: 2–5 calendar days
$104
|
| 222-0503E | 50.8 mm | 12 mm | BK7 | AR | 532 nm | AR | 532 nm |
Out of stock
Ships in: 62–65 calendar days
$178
|
| 222-1101E | 12.7 mm | 3 mm | UVFS | AR | 532 nm | AR | 532 nm |
2 in stock
Ships in: 2–5 calendar days
$78
|
| 222-1103E | 12.7 mm | 3 mm | UVFS | AR | 532 nm | AR | 532 nm |
Out of stock
Ships in: 62–65 calendar days
$99
|
| 222-1201E | 25.4 mm | 6 mm | FS | AR | 532 nm | AR | 532 nm |
Out of stock
Ships in: 62–65 calendar days
$84
|
| 222-1203E | 25.4 mm | 6 mm | UVFS | AR | 532 nm | AR | 532 nm |
Out of stock
Ships in: 62–65 calendar days
$134
|
| 222-1502E | 50.8 mm | 10 mm | UVFS | AR | 532 nm | AR | 532 nm |
1 in stock
Ships in: 2–5 calendar days
$212
|
| 222-1503E | 50.8 mm | 12 mm | UVFS | AR | 532 nm | AR | 532 nm |
Out of stock
Ships in: 62–65 calendar days
$255
|
| 223-1101E | 12.7 mm | 3 mm | UVFS | AR | 355 nm | AR | 355 nm |
Out of stock
Ships in: 62–65 calendar days
$78
|
| 223-1103E | 12.7 mm | 3 mm | UVFS | AR | 355 nm | AR | 355 nm |
Out of stock
Ships in: 62–65 calendar days
$99
|
| 223-1201E | 25.4 mm | 6 mm | UVFS | AR | 355 nm | AR | 355 nm |
Out of stock
Ships in: 62–65 calendar days
$84
|
| 223-1203E | 25.4 mm | 6 mm | UVFS | AR | 355 nm | AR | 355 nm |
Out of stock
Ships in: 62–65 calendar days
$134
|
| 223-1402E | 38.1 mm | 8 mm | UVFS | AR | 355 nm | AR | 355 nm |
Out of stock
Ships in: 62–65 calendar days
$152
|
| 223-1502E | 50.8 mm | 10 mm | UVFS | AR | 355 nm | AR | 355 nm |
10 in stock
Ships in: 2–5 calendar days
$212
|
| 224-1101E | 12.7 mm | 3 mm | UVFS | AR | 266 nm | AR | 266 nm |
3 in stock
Ships in: 2–5 calendar days
$95
|
| 224-1103E | 12.7 mm | 3 mm | UVFS | AR | 266 nm | AR | 266 nm |
Out of stock
Ships in: 62–65 calendar days
$116
|
| 224-1201E | 25.4 mm | 6 mm | UVFS | AR | 266 nm | AR | 266 nm |
Out of stock
Ships in: 62–65 calendar days
$102
|
| 224-1203E | 25.4 mm | 6 mm | UVFS | AR | 266 nm | AR | 266 nm |
Out of stock
Ships in: 62–65 calendar days
$150
|
| 224-1403E | 38.1 mm | 10 mm | UVFS | AR | 266 nm | AR | 266 nm |
Out of stock
Ships in: 62–65 calendar days
$212
|
| 224-1502E | 50.8 mm | 10 mm | UVFS | AR | 266 nm | AR | 266 nm |
Out of stock
Ships in: 62–65 calendar days
$218
|
We can make this for you
No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.
Specifications
| Shape Type | Round |
| Diameter Upper Tol | 0 mm |
| Diameter Lower Tol | -0.12 mm |
| Thickness Lower Tol | -0.2 mm |
| Thickness Upper Tol | 0.2 mm |
Surface 1
| Clear Aperture, % | >85 % |
| Power, fr @633 nm | 0 fr |
| Irregularity, fr @633 nm | 0.2 fr |
Surface 1, Wavelength 1
| Coating | AR |
| AOI (angle of incidence) | 0 deg |
Surface 2
| Clear Aperture, % | >85 % |
| Power, fr @633 nm | 0 fr |
| Irregularity, fr @633 nm | 0.2 fr |
Surface 2, Wavelength 1
| Coating | AR |
| AOI (angle of incidence) | 0 deg |
Description
- Made of high quality UV FS and BK7
- AR coated at 266 nm, 355 nm, 532 nm or 1064 nm
Featuring high optical transmission with little distortion of the transmitted signal, precision windows are a good solution for Nd:YAG laser applications that require protective windows.
