Ultra-Fine Adjustment Screws 870-0080 SKU: 870-0080-B2
• Stainless steel screw with pitch of 0.25 mm • Precision brass collars of 3 types • Tolerances better than tightest industry standards Ultra-Fine Adjustment Screws 870-0080 are compact and provide extremely high resolution. Special design provides a smooth and repeatable…
Variant specifications
| Specification | Value |
|---|---|
| Travel | 7 mm |
| Length | 19 mm |
| Tip | blunt tip |
Shared product specifications
These specifications apply across the Ultra-Fine Adjustment Screws 870-0080 product family.
| Adjustment screw thread | M6x0.25 |
| Sensitivity | 0.5 µm |
| Axial load capacity | 50 N |
| Weight | 0.01 to 0.02 kg |
| Ultra-Fine Adjustment Screws - Solidworks file | |
| Ultra-Fine Adjustment Screws - DWG file |
Product brochures
Shared documentation for the complete product family.
