Positioning Mount 840-0199 for Nonlinear Crystal Housing SKU: 840-0199
• Accepts Ø 25.4 mm and up to 10.5 mm thickness ring housings • Kinematic design • Wedge and ball drive mechanism • Tilt/tip range: ±2° • Sensitivity: 3 arcsec • Fine adjustment screws with 0.25 mm pitch • Hardened seats under adjustment screws • Rotation range: 360° • Scale…
Variant specifications
| Product | Value |
|---|---|
| Product Type | Manual Optical Positioner, 2-screws |
| Mount Material and Coating | Black Anodised Aluminum |
| Angular Tilt Range | 4 Deg |
| Tilt Sensitivity | 0 deg 0 min 3 sec |
| Mount Clear Aperture | 23 mm |
| Weight | 0.12 kg |
| Mounting Thread | M4 |
| Mounted Optics Diameter | 25.4 mm - 25.4 mm |
| Width | 55 mm |
| Length | 28 mm |
| Height | 77 mm |
| Number of Axes | 3 |
