Color Glass Filters SKU: 243-3990
Color Glass Filters are made from optically polished highest quality Schott colored optical glass. The spectral properties of these color filters are uniform over the entire aperture and independent of angle of incidence. Color Glass Filters can be used alone or in conjunction…
Variant specifications
| Specification | Value |
|---|---|
| Material | RG1000 |
| Dimensions | 25.4x25.4 mm |
| Group | Rectangular, 25.4x25.4 mm |
Shared product specifications
These specifications apply across the Color Glass Filters product family.
| Material | Schott colored glass |
| Surface quality | 60-40 scratch & dig (MIL-PRF-13830B) |
| Surface flatness | 1 λ per inch @ 633 nm |
| Parallelism | 3 arcmin |
| Diameter tolerance | +0.0 / -0.2 mm |
| Thickness | 3.0 ± 0.2 mm |
| Clear aperture | 90% of diameter |
Variant files
Technical drawings, models and data files for SKU 243-3990.
Product brochures
Shared documentation for the complete product family.
