Femtoline Laser Harmonic Separators with High Transmission SKU: 045-0845HT
Harmonic separators with high transmission are dichroic beamsplitters that reflect one wavelength and transmit the other. The main advantage of a harmonic separator with high transmission is transmitted wavelength - T>98%@515 nm + T>99%@1030 nm, also the rear surface of harmonic…
Variant specifications
| Specification | Value |
|---|---|
| Material | UVFS |
| Diameter | ø50.8 mm |
| Thickness | 8 mm |
| REFLECTED WAVELENGTH S AND P POL | R>99.9%@760-840 nm |
| TRANSMITTED WAVELENGTH S AND P POL | Tave>95%@380-420 nm |
| AOI | 45° |
Shared product specifications
These specifications apply across the Femtoline Laser Harmonic Separators with High Transmission product family.
Substrate
| Material | UV grade Fused Silica |
| S1 Surface Flatness | λ / 10 typical at 633 nm |
| S1 Surface Quality | 20-10 scratch & dig (MIL-PRF-13830B) |
| S2 Surface Flatness | λ / 10 typical at 633 nm |
| S2 Surface Quality | 20-10 scratch & dig (MIL-PRF-13830B) |
| Diameter Tolerance | +0.00 mm-0.12 mm |
| Thickness Tolerance | ±0.25 mm |
| Parallelism | <30 arcsec |
| Chamfer | 0.3 mm at 45° typical |
Coating
| Technology | Ion beam sputtering |
| Adhesion and Durability | Per MIL-C-675A. Insoluble in lab solvents |
| Clear Aperture | Exceeds central 85% of diameter |
| Coated Surface Flatness | λ / 8 at 633 nm over 80% of diameter |
| Transmitted Wavefront Distortion (TWD) | λ / 10 over clear aperture |
| Back Side Antireflection Coated | AOI 45°, R<0.5%, (s+p) / 2 / AOI 0°, R<0.1% |
| Laser Damage Threshold | > 0.3 J / cm², 200 fs, 100 Hz, 343 nm, p-pol >0.7 J / cm², 10 ps, 50 kHz, 343 nm, p-pol |
Classification
| Line | femtoline |
