Elliptical Windows
• Made of BK-7 glass or UV fused silica • Polished to high surface quality (20-10 scratch & dig) • Excellent for beam directing applications Elliptical flat mirrors bend light at precise angles with minimum wave… Read more →
Volume discount
- 5–9 units −5%
- 10+ units −10%
Applied in your cart. Quantities of any variant of this product count together.
Configure & order — pick a catalog variant or configure your own
Product
| SKU | Diameter | Thickness | Material Type | Material | Coating S1W1 | Coating S2W1 | |
|---|---|---|---|---|---|---|---|
| 020-0183A | 18 mm | 3 mm | BK7 | BK7 | — | — |
Out of stock
Ships in: 58–61 calendar days
$57
|
| 020-0183B | — | 3 mm | BK7 | BK7 | Uncoated | Uncoated |
Out of stock
Ships in: 62–65 calendar days
$57
|
| 020-0254A | — | 4 mm | BK7 | BK7 | Uncoated | Uncoated |
2 in stock
Ships in: 2–5 calendar days
$65
|
| 020-0254B | — | 4 mm | BK7 | BK7 | Uncoated | Uncoated |
1 in stock
Ships in: 2–5 calendar days
$65
|
| 020-0304A | — | 4 mm | BK7 | BK7 | Uncoated | Uncoated |
2 in stock
Ships in: 2–5 calendar days
$75
|
| 020-0304B | — | 4 mm | BK7 | BK7 | Uncoated | Uncoated |
10 in stock
Ships in: 2–5 calendar days
$75
|
| 020-1183A | — | 3 mm | FS | UVFS | Uncoated | Uncoated |
4 in stock
Ships in: 2–5 calendar days
$94
|
| 020-1183B | — | 3 mm | FS | UVFS | Uncoated | Uncoated |
Out of stock
Ships in: 62–65 calendar days
$94
|
| 020-1254A | 25 mm | 4 mm | FS | UVFS | — | — |
Out of stock
Ships in: 58–61 calendar days
$100
|
| 020-1254B | — | 4 mm | FS | UVFS | Uncoated | Uncoated |
Out of stock
Ships in: 62–65 calendar days
$100
|
| 020-1304A | 30 mm | 4 mm | FS | UVFS | — | — |
3 in stock
Ships in: 2–5 calendar days
$131
|
| 020-1304B | — | 4 mm | FS | UVFS | Uncoated | Uncoated |
1 in stock
Ships in: 2–5 calendar days
$131
|
We can make this for you
No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.
Specifications
| Shape Type | Other |
Surface 1
| Surface quality, ISO | 20-10 |
| Power and Irregularity, fringes @633 nm | -(0.5) |
| Irregularity, fringes @633 nm | 0.5 fr |
Description
- Made of BK-7 glass or UV fused silica
- Polished to high surface quality (20-10 scratch & dig)
- Excellent for beam directing applications
Elliptical flat mirrors bend light at precise angles with minimum wave distortion due to elongated major axis. Precision 45 degree elliptical flat mirrors are ideal for technical and astronomical applications.
Elliptical windows can be supplied coated with our standard metallic or high-reflectivity dielectric coatings (see the Coatings section of the Optical Components catalog).
If you would like to order an elliptical mirror substrate with coating, please note the code of the window and the code of the coating in your request.
