Glan-Taylor Polarizing Prisms SKU: POL0001764
• Made from natural calcite • Air-spaced • Extinction ratio - 1:100 000 Natural calcite Glan-Taylor polarizing prisms transmit linearly polarized extraordinary beam and deflect the ordinary beam to the housing. Glan-Taylor prisms are designed for operation across the…
Variant specifications
| Specification | Value |
|---|---|
| Description | a-BBO, 260-360 nm, Mount Ø 30 mm, CA Ø 15 mm |
Shared product specifications
These specifications apply across the Glan-Taylor Polarizing Prisms product family.
| Material | Natural calcite |
| Surface quality (input / exit faces) | 60-40 scratch & dig (MIL-PRF-13830B) |
| Wavefront distortion | λ / 4 at 633 nm |
| Beam deviation | <10 arcmin |
| Wavelength | 220-2300 nm |
| Extinction ratio | 1:100 000 |
| Laser Damage Threshold | 0.5 J / cm² 10 ns pulses at 1064 nm |
Classification
| Type | Glan-Taylor|Glan-Laser|prism |
