Femtoline Low GDD Ultrafast Mirrors SKU: 037-0400-i0
Laser mirrors for femtosecond applications are designed to have a broad operating wavelength range and linear phase versus frequency characteristics (low group delay dispersion (GDD)). The coating is a single layer dielectric and has no phase shift over the operating wavelength…
Variant specifications
| Specification | Value |
|---|---|
| D | 76.2 mm |
| AOI | 0° |
| Wavelength | 380-420 nm |
| Application | Ti:Sa 2H |
| ET | 12.7 mm |
| R, % (S+p)/2 | 99.8% |
Shared product specifications
These specifications apply across the Femtoline Low GDD Ultrafast Mirrors product family.
| Material | UV grade Fused Silica or BK7 glass |
| S1 Surface Flatness | λ / 10 at 633 nm |
| S1 Surface Quality | 20-10 scratch & dig (MIL-PRF-13830B) |
| S2 Surface Quality | Commercial polish |
| Diameter Tolerance | +0.00 mm-0.12 mm |
| Thickness Tolerance | ±0.25 |
| Wedge | <3 min |
| Chamfer | 0.3 mm at 45° typical |
| Technology | Electron beam multilayer dielectric or Ion Beam Sputtering |
| Adhesion and Durability | Per MIL-C-675A. Insoluble in lab solvents |
| Clear Aperture | Exceeds central 85% of diameter |
| Coating | Hard dielectric High Reflection R>99.5% |
| Designed for Average Polarization | R=(Rs+Rp) / 2 |
| Laser Damage Threshold | >100 mJ / cm², 50 fsec, 50 Hz, 800 nm typical |
| Coated Surface Flatness | λ / 10 at 633 nm over clear aperture |
| Angle of Incidence | 0 or 45±3 degrees |
Classification
| Line | femtoline |
