Barium Nitrate Crystals - Ba(NO3)2 SKU: BNO-501
Ba(NO3)2 has the highest Raman gain coefficient among other SRS crystals. The gain coefficient affects the threshold for Raman laser. However, the thermal lensing is particularly strong in this material. This is indicated by the large value of dn/dT and low thermal…
Variant specifications
| Specification | Value |
|---|---|
| Dimensions | 5 x 5 x 20 mm |
| Coating | AR/AR@1064-1198 nm |
Shared product specifications
These specifications apply across the Barium Nitrate Crystals - Ba(NO3)2 product family.
Ba(NO3)2 Physical and Optical Properties
| Crystal symmetry | Cubic, P213 |
| Transmission range | 0.35-1.8 µm |
| Density | 3.25 g/cm3 |
| Hardness Mohs | 2.5-3 |
| Refractive indices @ 1064 nm | n = 1.555 |
| Raman shift | 1048 cm-1 |
| Raman gain, pump 1064 nm | 11 cm/GW |
| Thermal conductivity, W/mK | 1.17 |
| dn/dT | -20 x 10-6 K-1 |
| Optical Damage threshold | ˜0.4 GW/cm2 |
