Barium Nitrate Crystals - Ba(NO3)2
Ba(NO3)2 has the highest Raman gain coefficient among other SRS crystals. The gain coefficient affects the threshold for Raman laser. However, the thermal lensing is particularly strong in this material. This is… Read more →
Listed in
Configure & order — pick a catalog variant or configure your own
| SKU | Dimensions · Coating | |
|---|---|---|
| BNO-501 | 5 x 5 x 20 mm·AR/AR@1064-1198 nm |
Out of stock
—
|
| BNO-502 | 5 x 5 x 50 mm·AR/AR@1064-1198 nm |
Out of stock
—
|
| BNO-503 | 5 x 5 x 50 mm·AR/AR@532-563 nm |
Out of stock
—
|
We can make this for you
No catalog variant matches your exact spec. Add it to your cart as a quote request — sales will confirm price and lead time within 1 business day.
Specifications
Ba(NO3)2 Physical and Optical Properties
| Crystal symmetry | Cubic, P213 |
| Transmission range | 0.35-1.8 µm |
| Density | 3.25 g/cm3 |
| Hardness Mohs | 2.5-3 |
| Refractive indices @ 1064 nm | n = 1.555 |
| Raman shift | 1048 cm-1 |
| Raman gain, pump 1064 nm | 11 cm/GW |
| Thermal conductivity, W/mK | 1.17 |
| dn/dT | -20 x 10-6 K-1 |
| Optical Damage threshold | ˜0.4 GW/cm2 |
Description
Ba(NO3)2 has the highest Raman gain coefficient among other SRS crystals. The gain coefficient affects the threshold for Raman laser. However, the thermal lensing is particularly strong in this material. This is indicated by the large value of dn/dT and low thermal conductivity.
Ba(NO3)2 crystals are used as Stimulated Raman Scattering (SRS) converters that provide non-linear conversion of laser radiation frequency due to Stimulated Raman Scattering effect. They can be used as frequency converters in tunable lasers for the extention of their tuning range.
Ba(NO3)2 crystals can also be used as a substitute for laser radiation frequency converters based on organic dye solution. This greatly improves the devices' performance characteristics.
Ba(NO3)2 crystals are free from bubbles and inclusions. The optical uniformity of Ba(NO3)2 crystals is comparable with the quality of barium and calcium fluoride crystals. Transmission band is from 0.35 µm up to 1.8 µm. The crystals can be used in the range from 1.8 µm up to 2.4 µm as optical filters.
