Rectangular Mirrors SKU: VEI0009284
Variant specifications
| Specification | Value |
|---|---|
| Length | 88.9 |
| Thickness | 10 |
| Description | UVFS High Reflectivity flat octagonal mirror, 88.9x63.5mm (corners cut at 45deg), thickness 10mm, SQ 20-10s/d, substrate SF l/8@633nm, IBS coated HR>99.8%@1000-1080nm, AOI=45deg, high damage threshold LDT>1 J/cm2, 400fs, 1kHz / LDT>6 J/cm2, 500ps, 1kHz. |
