Rectangular Mirrors

Rectangular Mirrors
From $47 Configure & order →

Volume discount

  • 5–9 units −5%
  • 10+ units −10%

Applied in your cart. Quantities of any variant of this product count together.

Listed in

Configure & order — pick a catalog variant or configure your own

Length Any
Catalog band: 10.5–88.9
Manufacturable: 10.5–88.9
10.5 88.9
or
Thickness Any
Catalog band: 0.0–10.0
Manufacturable: 0.0–10.0
0.0 10.0
or
6 catalog variants — refine the spec to narrow it down.
SKU Length · Description · Thickness
VEI0003465 28.6·UVFS Thin Film polarizer, size 28.6x14.3x3mm, SQ 20-10s/d, SF l/10@633nm, parall 30", coated Rs/Tp>99/98%@532nm, AOI=56deg.·3
Out of stock Ships in: 58–61 calendar days
$164
VEI0007617 15·UVFS pl mirror 7x15x3 mm, Au+protection. S2: ground.·3
Out of stock Ships in: 58–61 calendar days
$71
VEI0009264 24·UVFS flat mirror, 17x24x1,1 mm, SQ 20-10s/d, TWD l/10@633nm, coated HRsp>99.7%@343 nm, AOI=45deg·1.1
Out of stock Ships in: 58–61 calendar days
$47
VEI0009265 10.5·UVFS flat mirror, 17x10,5x0,4 mm, SQ 20-10s/d, TWD l/10@633nm, coated HRsp>99.7%@343 nm, AOI=45deg, with one curner cut 1,2x1,2 mm x 45 deg·0.4
Out of stock Ships in: 58–61 calendar days
$47
VEI0009284 88.9·UVFS High Reflectivity flat octagonal mirror, 88.9x63.5mm (corners cut at 45deg), thickness 10mm, SQ 20-10s/d, substrate SF l/8@633nm, IBS coated HR>99.8%@1000-1080nm, AOI=45deg, high damage threshold LDT>1 J/cm2, 400fs, 1kHz / LDT>6 J/cm2, 500ps, 1kHz.·10
Out of stock Ships in: 58–61 calendar days
$176
VEI0009309 25.4·UVFS pl/cv cyl, 25,4x25,4 mm, ct=10 mm, R=--88 mm, SQ 20-10 s/d, Au protected·0
Out of stock Ships in: 58–61 calendar days
$71

We can make this for you

No catalog variant matches your exact spec. Add it to your cart as a custom item — sales will confirm price and lead time within 1 business day.
